DLB-1200 Network Load Balancer User Manual
1
、
I
NTRODUCTION
1-1、Product Overview
Thank you for using DLB-1200. We have designed a simple installing process and WEB
interface; let you enjoy easily the best network environment. By several ISP lines linking
outside with DLB-1200, it either can construct a more reliable multi-line network environment
or avoid losing due to ISP or component problem. Besides, DLB-1200 also can integrate all
bandwidth of WAN linked outside to raise highly usage efficiency of enterprises' network. This
manual provides the necessary information for DLB-1200 hardware device, software setting
and configuration parameters.
1-2、Unpacking
Open the shipping carton of DLB-1200, and this carton should contain the following item:
♦ DLB-1200
♦ DLB-1200 User Manual
♦ DLB-1200 Quick Installation Guide
♦ Power adapter（5V/3A）RJ-45 Cable×3
♦ Console Cable
1-3、Identifying External Components
1
-3-a
、
Front Panel
♦ Power Indicator
4
