![Lowara NSCF 300-450/3150/W45 VDC4 [100/204] E nsc series operating characteristics at 50 hz 4 poles](/img/pdf.png)
Lowara NSCF 300-450/3150/W45 VDC4 [100/204] E nsc series operating characteristics at 50 hz 4 poles
![Lowara NSCF 300-350/750A/W45 VDC4 [100/204] E nsc series operating characteristics at 50 hz 4 poles](/views2/1622664/page100/bg64.png)
100
e-NSC SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
0 50 100 150 200 250
P
P
[kW]
0
10
20
30
40
0 5 101520253035404550556065
P
P
[HP]
0
10
20
30
40
50
NPSH [m]
0
5
10
15
20
NPSH [ft]
0
10
20
30
40
50
60
Q
[m³/h]
Q
[l/s]
H
[m]
10
20
30
40
50
60
70
0 100 200 300 400 500 600 700 800 900 1000 1100
H [ft]
40
60
80
100
120
140
160
180
200
220
0 100 200 300 400 500 600 700 800 900
Q
[US gpm]
Q
[Imp gpm]
73.8
72.5
71.3
55
70
50
65
η
ηη
η
[%]
65
70
69.9
60
60
~ 1450 [rpm]
ISO 9906:2012 - Grade 3BNSC 80-400
NSC80-400_4P50_B_CH
80-400/185
80-400/220
80-400/300
80-400/370
80-400/185
80-400/370
80-400/185
80-400/220
80-400/300
80-400/370
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
