137
NSCS 32, 40, 50 SERIES
DIMENSIONS AND WEIGHTS AT 50 Hz, 2 POLES
DIMENSIONI E PESI SERIE NSCS 32-40-50 2 poli 50 Hz
PUMP TYPE WEIGHT
NSCS..2 BH L x
DNS DND a b f g1 h1 h2 m1 m2 n1 n2 P s1 W A AA AB AD B BB H HA s2 max max kg
32-125/11/S A 50 32 80 50 155 14 112 140 100 70 190 140 200 14 290 - - - 129 - - - - - 242 252 498 86 33
32-125/15/S A 50 32 80 50 155 14 112 140 100 70 190 140 200 14 290 - - - 129 - - - - - 242 252 498 86 34
32-125/22/P A 50 32 80 50 155 14 112 140 100 70 190 140 200 14 300 - - - 134 - - - - - 242 252 533 86 38
32-125/30/P A 50 32 80 50 165 14 112 140 100 70 190 140 250 14 310 - - - 134 - - - - - 250 265 543 86 43
32-160/22/P A 50 32 80 50 155 14 132 160 100 70 240 190 200 14 300 - - - 134 - - - - - 248 292 533 86 40
32-160/30/P A 50 32 80 50 165 14 132 160 100 70 240 190 250 14 310 - - - 134 - - - - - 250 292 543 86 44
32-160/40/P A 50 32 80 50 165 14 132 160 100 70 240 190 250 14 338 - - - 154 - - - - - 250 292 564 86 47
32-160/55/P A 50 32 80 50 192 14 132 160 100 70 240 190 300 14 399 - - - 168 - - - - - 300 318 647 86 56
32-200/30/P A 50 32 80 50 165 14 160 180 100 70 240 190 250 14 310 - - - 134 - - - - - 286 340 543 86 50
32-200/40/P A 50 32 80 50 165 14 160 180 100 70 240 190 250 14 338 - - - 154 - - - - - 286 340 564 86 54
32-200/55/P A 50 32 80 50 192 14 160 180 100 70 240 190 300 14 399 - - - 168 - - - - - 300 340 647 86 63
32-200/75/P A 50 32 80 50 192 14 160 180 100 70 240 190 300 14 397 - - - 191 - - - - - 300 351 639 86 80
32-250/75/P A 50 32 100 65 192 21 180 225 125 95 320 250 300 14 305 - - - 191 - - - - - 334 405 659 95 80
32-250/110A/P B 50 32 100 65 222 21 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 95 110
32-250/110/P B 50 32 100 65 222 21 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 95 114
32-250/150/P B 50 32 100 65 222 21 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 95 128
40-125/15/S A 65 40 80 50 155 14 112 140 100 70 210 160 200 14 290 - - - 129 - - - - - 237 252 498 96 35
40-125/22/P A 65 40 80 50 155 14 112 140 100 70 210 160 200 14 300 - - - 134 - - - - - 237 252 533 96 39
40-125/30/P A 65 40 80 50 165 14 112 140 100 70 210 160 250 14 310 - - - 134 - - - - - 250 265 543 96 44
40-125/40/P A 65 40 80 50 165 14 112 140 100 70 210 160 250 14 338 - - - 154 - - - - - 250 265 564 96 47
40-160/30/P A 65 40 80 50 165 14 132 160 100 70 240 190 250 14 310 - - - 134 - - - - - 250 292 543 92 46
40-160/40/P A 65 40 80 50 165 14 132 160 100 70 240 190 250 14 338 - - - 154 - - - - - 250 292 564 92 49
40-160/55/P A 65 40 80 50 192 14 132 160 100 70 240 190 300 14 399 - - - 168 - - - - - 300 318 647 92 60
40-160/75/P A 65 40 80 50 192 14 132 160 100 70 240 190 300 14 397 - - - 191 - - - - - 300 341 639 92 77
40-200/55/P A 65 40 100 50 192 14 160 180 100 70 265 212 300 14 399 - - - 168 - - - - - 300 340 667 90 64
40-200/75/P A 65 40 100 50 192 14 160 180 100 70 265 212 300 14 397 - - - 191 - - - - - 300 351 659 90 81
40-200/110A/P B 65 40 100 50 222 14 160 180 100 70 265 212 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 90 115
40-200/110/P B 65 40 100 50 222 14 160 180 100 70 265 212 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 90 119
40-250/110A/P B 65 40 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 104 126
40-250/110/P B 65 40 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 104 130
40-250/150/P B 65 40 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 104 144
40-250/185/P B 65 40 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 254 304 160 5 15 350 420 816 104 154
40-250/220/P B 65 40 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 254 304 160 5 15 350 420 816 104 155
50-125/30/P A 65 50 100 50 167 14 132 160 100 70 240 190 250 14 312 - - - 134 - - - - - 255 292 565 107 47
50-125/40/P A 65 50 100 50 167 14 132 160 100 70 240 190 250 14 340 - - - 154 - - - - - 255 292 586 107 50
50-125/55/P A 65 50 100 50 194 14 132 160 100 70 240 190 300 14 401 - - - 168 - - - - - 300 318 669 107 65
50-125/75/P A 65 50 100 50 194 14 132 160 100 70 240 190 300 14 399 - - - 191 - - - - - 300 341 661 107 82
50-160/55/P A 65 50 100 50 192 14 160 180 100 70 265 212 300 14 399 - - - 168 - - - - - 300 340 667 103 67
50-160/75/P A 65 50 100 50 192 14 160 180 100 70 265 212 300 14 397 - - - 191 - - - - - 300 351 659 103 84
50-160/110A/P B 65 50 100 50 222 14 160 180 100 70 265 212 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 103 118
50-160/110/P B 65 50 100 50 222 14 160 180 100 70 265 212 350 14 330 254 49 304 240 210 304 160 5 15 350 420 816 103 122
50-200/110A/P B 65 50 100 50 222 14 160 200 100 70 265 212 350 14 332 254 49 304 240 210 304 160 5 15 350 380 816 98 118
50-200/110/P B 65 50 100 50 222 14 160 200 100 70 265 212 350 14 332 254 49 304 240 210 304 160 5 15 350 380 816 98 122
50-200/150/P B 65 50 100 50 222 14 160 200 100 70 265 212 350 14 332 254 49 304 240 210 304 160 5 15 350 420 816 98 139
50-200/185/P B 65 50 100 50 222 14 160 200 100 70 265 212 350 14 332 254 49 304 240 254 304 160 5 15 350 420 816 98 149
50-250/150/P B 65 50 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 210 304 160 5 15 352 420 816 110 145
50-250/185/P B 65 50 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 254 304 160 5 15 352 420 816 110 155
50-250/220/P B 65 50 100 65 222 16 180 225 125 95 320 250 350 14 330 254 49 304 240 254 304 160 5 15 352 420 816 110 166
50-250/300/W B 65 50 100 65 228 16 180 225 125 95 320 250 400 14 361 318 82 385 317 305 370 200 30 18 402 517 985 110 260
50-315/370/W B 65 50 125
65
246 14 225 280 125 95 345 280 400 15 379 318 82 385 317 305 370 200 30 19 413 542 1028 140 354
50-315/450/W B 65 50 125
65
246 14 225 280 125 95 345 280 450 15 395 356 80 436 384 311 412 225 34 19 450 609 1117 140 510
50-315/550/W C 65 50 125
65
276 14 225 280 125 95 345 280 550 15 444 406 100 506 402 349 467 250 43 24 550 682 1226 140 592
50-315/750/W C 65 50 125
65
276 14 225 280 125 95 345 280 550 15 466 457 100 557 472 368 517 280 42 24 550 752 1332 140 834
For shims and supports see accessories section.
nscs-32-40-50_2p50-en_d_td
NOTE: Pumps with flanges according to EN 1092-2 as standard; available ASME B16.5 version on request.
