6
e-NSC SERIES
for COMMERCIAL BUILDING SERVICES (CBS)
APPLICATIONS & BENEFITS
Benefits
The e-NSC Series permit to achieve the following benefits.
• Performances: the e-NSC pumps are ErP 2015 compliant, equipped with IE3 motors and with the right hydraulic
coverage for CBS applications. The standard full cast iron version with PN16 *, 140 °C * maximum fluid temperature
and EPDM elastomer is exactly what the CBS Market needs.
• Reliability: the high quality in production, the robust construction and operation, the easily interchangeable
mechanical seals, and wear rings guarantee a continuous operation without faults and a shorter down time for
maintenance.
• Versatility: beside the standard offer, the e-NSC series is available in many different material configurations for
casing, impeller, and elastomers as well as different construction methods to address a wide range of applica-
tions.
• Total cost ownership: the best hydraulic and electric efficiency, the HYDROVAR-equipped versions, the easy
and quick maintenance, permit to reduce the operation and maintenance cost and to save energy when the pump
is working.
• Pre-post sales support: we are continuously working close to our customers to help them in selecting the
right pump for the specific application. An improved user-friendly selection software improved with many selection
tools is available on the website, on DVD or on Apps for mobile phones. Experienced engineers are fully dedicated
to big projects for Municipality.
Features
Discharge ports DN32 to DN300 *.
Wide performance range up to 154 m head and 1900 m³/h flow.
Nominal pressure of 16 bar *.
Wide range of temperatures for pumped liquids: -25°C to +140°C *.
Wide range of materials for many different kinds of pumped liquid.
Wide range of voltages.
High performance IE3 motors.
Variable speed by optional HYDROVAR drive.
* NSC2 models: PN12, 120 °C, suction 2”, discharge 1¼”.
Applications
The e-NSC series is suitable for many different applications demanding reliable and efficient products that require
constant or variable duty points in cost saving operation.
The e-NSC Series can be used for the following CBS ap-
plications:
• HVAC
- Liquid transfer in heating systems.
- Liquid transfer in air-conditioning systems.
- Liquid transfer in ventilation systems.
• Water Supply
- Pressure boosting in commercial buildings.
- Irrigation systems.
- Water transfer for green houses.
• Fire Fighting
