110
e-NSC SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
0 100 200 300 400 500 600
P
P
[kW]
6
8
10
12
14
16
0 20 40 60 80 100 120 140 160
P
P
[HP]
8
10
12
14
16
18
20
NPSH [m]
2
4
6
8
NPSH [ft]
10
15
20
25
Q
[m³/h]
Q
[l/s]
H
[m]
5
10
15
0 500 1000 1500 2000 2500
H [ft]
10
15
20
25
30
35
40
45
50
55
0 500 1000 1500 2000
Q
[US gpm]
Q
[Imp gpm]
83.9
65
75
70
60
50
η
ηη
η
[%]
80
80.7
82
80
78.8
75
70
150-200/110A
150-200/110
150-200/150A
150-200/150
150-200/150
150-200/110A
150-200/110
150-200/150A
150-200/150
~ 1450 [rpm]
ISO 9906:2012 - Grade 3B
NSC 150-200
NSC150-200_4P50_B_CH
