![Lowara NSCF 300-450/3150/W45 VDC4 [68/204] E nsc series operating characteristics at 50 hz 2 poles](/img/pdf.png)
Lowara NSCF 300-450/3150/W45 VDC4 [68/204] E nsc series operating characteristics at 50 hz 2 poles
![Lowara NSCF 300-350/750A/W45 VDC4 [68/204] E nsc series operating characteristics at 50 hz 2 poles](/views2/1622664/page68/bg44.png)
68
e-NSC SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 2 POLES
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
NSC 80-200 ~ 2900 [rpm] ISO 9906:2012 - Grade 3B
0 200 400 600 800 1000
0 10 20 30 40 50 60 70 80
Q [Imp gpm]
Q [l/s]
80-200/450
80-200/370
80-200/300
80-200/220
83.3
82.6
81.8
79.7
82
82
80
80
78
76
74
72
0 200 400 600 800 1000 1200
0
50
100
150
200
0
10
20
30
40
50
60
70
Q [US gpm]
H [ft]
H[m]
η[%]
η[%]η[%]
η[%]
80-200/450
0
10
20
30
0
4
8
12
NPSH[ft]
NPSH[m]
80-200/450
80-200/370
80-200/300
80-200/220
0
20
40
60
0
10
20
30
40
50
0 50 100 150 200 250 300
Pp[HP]
Pp[kW]
Q [m
3
/h]
NSC80
-
200_2P50_D_CH
