Ecodesign Directive (ErP)
Over last decade the European Commission with the ‘Energy Efficiency Plan’ pushed the European Parliament
and the Council to adopt specific measures to the purpose of reducing energy consumption and further negative
environmental impacts.
Through the Directives 2005/32/EC, energy-using products (EuP), and 2009/125/EC, energy-related products
(ErP) a framework for ecodesign requirements was established.
The Commission Regulations (EC) No 640/2009 and (EU) No 4/2014 have implemented two directives with re-
gard to ecodesign requirements for three-phase 50 Hz electric motors placed on the market and put into
service inside EU zone as self-alone units or integrated in other products.
This regulation states that motors must have efficiency level IE3 (or IE2 + Variable Speed Drive) from
1 January 2015 for 7,5 to 375 kW rated powers and from 1 January 2017 for 0,75 to 375 kW ones.
The Commission Regulation (EU) No 547/2012 has implemented two directives with regard to ecodesign requi-
rements for some types of clean water pumps placed on the market and put into service inside EU zone as
self-alone units or integrated in other products.
This regulation states that water pumps shall have index MEI 0.4 as minimum from 1 January 2015.
That index comes from a dedicated formula which considers hydraulic efficiency values at ‘best efficiency point’
(BEP), 75 % of the flow at BEP (Part load – PL) and 110 % of the flow at BEP (Over load – OL).
The e-NSC series, for the models in the scope of the regulations above, is ErP compliant, ha-
ving an index MEI equal or higher than 0,4 and IE3 motor efficiency.
Xylect
TM
Xylect
TM
is a pump solution software with an extensive online database of product information across the entire
range of pumps and related products, with multiple search options and helpful project management facilities.
The system holds up-to-date product information on thousands of products and accessories.
Xylect
TM
can be available:
On the website – www.xylect.com On DVD – Loop 4U On Mobile Apps
For more information, please, see page 199-200.
