![Lowara NSCF 300-450/3150/W45 VDC4 [88/204] E nsc series operating characteristics at 50 hz 4 poles](/img/pdf.png)
Lowara NSCF 300-450/3150/W45 VDC4 [88/204] E nsc series operating characteristics at 50 hz 4 poles
![Lowara NSCF 150-500/2000/W45 VDC4 [88/204] E nsc series operating characteristics at 50 hz 4 poles](/views2/1622664/page88/bg58.png)
88
e-NSC SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
NSC 50-200 ~ 1450 [rpm] ISO 9906:2012 - Grade 3B
0 50 100 150 200
0 2 4 6 8 10 12 14 16
Q [Imp gpm]
Q [l/s]
50-200/22
50-200/22A
50-200/15
50-200/**
73.3
72
70.5
68.9
72
72
70
70
68
68
66
66
64
64
62
0 50 100 150 200 250
0
10
20
30
40
50
0
2
4
6
8
10
12
14
16
Q [US gpm]
H [ft]
H[m]
η[%]
η[%]η[%]
η[%]
50-200/22
0
2
4
6
8
0
1
2
3
NPSH[ft]
NPSH[m]
50-200/22
50-200/22A
50-200/15
50-200/**
0
1
2
3
0.0
0.5
1.0
1.5
2.0
2.5
0 10 20 30 40 50 60
Pp[HP]
Pp[kW]
Q [m
3
/h]
NC50
-
200_4P50_D_CH
**= 1.1 kW (/11) NSCS, NSCF, NSCC **= 1.5 kW (/15A) NSCE
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
