ESIE06-05 General Outline
Part 1 – System Outline 1–5
3
1
4
5
1.2 Technical Specifications: EWAQ080-260DAYN
Technical
specifications
The table below contains the technical specifications.
EWAQ080DA
YN
EWAQ100DA
YN
EWAQ130DA
YN
EWAQ150DA
YN
EWAQ180DA
YN
EWAQ210DAY
N
EWAQ240DA
YN
EWAQ260DA
YN
Capacity (Eurov-
ent conditions
specified in
notes)
Cooling Nomi-
nal
kW 80 105 131 152 182 209 236 254
Capacity Steps % 0-50-100 0-50-100 0-25
50-75-100
0-25
50-75-100
21/29-43/50/
57-71/79-10
0
0-25
50-75-100
22/28-40/50/
56-72/78-10
0
0-25
50-75-100
Nominal input
(Eurovent condi-
tions specified in
notes)
Cooling kW 26.4 36.2 46.6 56.3 64.5 74.6 82.2 94.0
EER
3.03 2.90 2.81 2.70 2.82 2.80 2.80 2.70
ESEER
4.12 4.00 4.34 4.22 4.36 4.32 4.20 4.00
Casing Colour
Ivory white
Material Polyester painted galvanised steel plate/Munsell code 5Y7.5/1
Dimensions Unit Height mm 2311 2311 2311 2311 2311 2311 2311 2311
Width mm 2000 2000 2000 2000 2000 2000 2000 2000
Depth mm 2566 2566 2631 2631 3081 3081 4850 4850
Weight Unit kg 1350 1400 1500 1550 1800 1850 3150 3250
Operating weight kg 1315 1415 1517 1569 1825 1877 3189 3292
Gross weight kg 1400 1450 1550 1600 1850 1900 3200 3300
Water Heat
Exchanger
Type Brased plate
Filter Type
STRAINER GALVANIZED
Diam-
eter
perfo-
ration
s
mm 1 1 1 1 1 1 1 1
Minimum water vol-
ume in the system
l 358 470 295 341 408 468 529 569
Water
flow
rate
Min l/min 115 151 188 218 261 300 339 364
Max l/min 459 602 754 871 1043 1198 1355 1456
Nomi-
nal
Water
Flow
Cool-
ing
l/min 229 301 377 436 522 599 677 728
Nominal Water
Flow
Cooling Total kPa 59 58 52 49 52 53 51 47
Water Heat
Exchanger
Insulation material Foamed synthetic elastomer
Model Quan-
tity
11111 1 11
Model PT120 PT120 DV47 DV47 DV58 DV58 DV58 DV58
