![Daikin EWYQ210DAYN [399/524] Simulation](/views2/1657857/page399/bg18f.png)
ESIE06-05 Functional Control for a Standalone Unit
Part 2 – Functional Description 2–173
3
2
4
5
1
3.25 Simulation
This is an operation mode for the controller in a simulation board because then the actual unit and
components are replaced by electrical and electronic components. These components would not allow
correct operation of the controller if it was in normal mode.
This mode can only be used on simulation boards.
Possible settings (Service/Advanced menu):
■ Simulation setting:
■ AI Setting:
■ DIS. EEV Setting:
Simulation parameter Application
Simulation = NO actual unit
Simulation = YES simulation board is selected
Simulation parameter Application
AI = 0 actual unit = actual sensors are used on
the analog inputs
AI = 1 simulation board (all analog inputs use
potentiometers = NTC)
Simulation parameter Application
DIS. EEV = 0 actual unit with EEV driver
DIS. EEV = 1 If no EEV driver is connected to the
simulation board this parameter should
be put on 1. This will disable the EEV
control on the controller.
