ESIE06-05 General Outline
Part 1 – System Outline 1–19
3
1
4
5
1.12 Electrical Specifications: EWAQ080-260DAYN
Electrical
specifications
The table below contains the electrical specifications.
EWAQ080
DAYN
EWAQ100D
AYN
EWAQ130D
AYN
EWAQ150D
AYN
EWAQ180D
AYN
EWAQ210D
AYN
EWAQ240DA
YN
EWAQ260D
AYN
Power supply Phase 3 3 3 3 3 3 3 3
Frequency Hz 50 50 50 50 50 50 50 50
Voltage V 400 400 400 400 400 400 400 400
Voltage
Tol er an ce
Minimum % -10%
Maximum % +10%
Unit Starting current A 201
(max.
240)
221 (max.
272)
161 (max.
269)
199 (max.
320
221(max.
357)
221 (max.
368)
266 (max.
426)
266 (max.
468)
Nominal Running Current
Cooling
A 60 72 88 113 131 144 162 181
Maximum Running Cur-
rent
A 96 120 160 177 209 233 262 290
Recommended fuses according to
IEC standard 269-2
3x125gL 3x160gL 3x200gL 3x200gL 3x250gL 3x250gL 3x300gL 3x355gL
Fan Starting method Direct On-Line
Maximum Running Cur-
rent
A 1.5 1.5 1.4 2.1 2.1 2.1 1.6 1.6
Compressor Starting current A 195 215 158 195 195/215 215 215/260 260
Nominal Running Current
(RLA)
A 25/25 31/31 19/19 25/25 25/31 31/31 31/40 40/40
Maximum Running Cur-
rent
A 39 51 35 39 39/51 51 51/65 65
Starting method Direct On-Line
Control circuit Phase 1 1 1 1 1 1 1 1
Frequency Hz 50 50 50 50 50 50 50 50
Voltage V 230V (supplied by factory installed transformers)
Crankcase heater
(E1/2HC)
W 2x75 2x75 4x65 4x75 4x75 4x75 75 75
Notes Starting current of the
unit = maximum running
current 4 fans + starting
current 1 compressor
Starting current of the unit =
maximum running current 2
fans(1 circuit) + starting cur-
rent 1 compressor
Starting current of the unit
= maximum running cur-
rent 3 fans(1 circuit) +
starting current 1 compres-
sor
Initial starting current =
maximum running current 4
fans + starting current 1
compressor
Maximum starting cur-
rent = maximum running
current 4 fans + maxi-
mum running current 1
compressor + starting
current 1 compressor
Maximum starting current of
the unit = maximum running
current 4 fans + maximum
running current 3 compres-
sors + starting current 1
compressor
Maximum starting current
= maximum running cur-
rent 6 fans + maximum
running current 3 compres-
sors + starting current 1
compressor
Maximum starting current =
maximum running current 8
fans + maximum running
current 3 compressors +
starting current 1 compres-
sor
