ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–65
3
2
4
5
1
2.15.3 Fan
Fan Control
Ambient
This screen allows modification of the ambient fan control used during the startup of the chiller.
Settings:
Fan Control This screen allows modification of the fan high pressure setpoints.
Settings:
AMBIENT TIMER : Time when the fan control based on ambient temperature is used at
the startup of a circuit
AMBIENT SETP A : Setpoint for high fan speed used in ambient fan control
AMBIENT SETP B : Setpoint for medium fan speed used in ambient fan control
_v
AMBIENT TIMER:070s
AMBIENT SETP A:15.0 °C
AMBIENT SETP B:05.0 °C
FAN CONTROL
FANST. A : High pressure setpoint for fan control
-First value: setpoint used for standard ON/OFF fans and units with inverter
fans
-Second value: setpoint used for inverter fans working in LOW NOISE mode
FANST. B1 : High pressure setpoint for fan control with standard ON/OFF fans
FANST B2 : High pressure setpoint for fan control
-First value: setpoint used for standard ON/OFF fans and units with inverter
fans
-Second value: setpoint used for inverter fans working in LOW NOISE mode
_v
FANST.
FANST.
FANST.
FAN CONTROL
A:18.9b/28.0b
B1:32.4b
B2:27.5b/35.0b
