1.21 Electrical Specifications for options: EWYQ230-250DAYN
Electrical
specifications
The table below contains the electrical specifications for the options of the EWYQ230-250DAYN.
Electrical specifications options
OPSP
Units EWYQ230DAYN* EWYQ250DAYN*
Std Pump Starting method Direct On-Line
Power kW 4,0 4,0
Maximum Running current A 8,0 8,0
Starting current A 98 98
OPHP
Units EWYQ230DAYN* EWYQ250DAYN*
High Esp Pump Starting method Direct On-Line
Power kW 7,5 7,5
Maximum Running current A 15,2 15,2
Starting current A 169 169
OP 10
Units EWYQ230DAYN* EWYQ250DAYN*
Heater Tape Supply Voltage V 230+/-10%
Recommended fuses A 2 x 10A
Power standard model 1 x 300W 1 x 300W
Power model with pump 2 x 300W 2 x 300W
Power model with pump and OPBT 2 x 300W + 1 x 150W 2 x 300W + 1 x 150W
