The Digital Controller For Multiscroll Chillers ESIE06-05
2–78 Part 2 – Functional Description
3
1
2
4
5
2.15.6 Input Output
Unit Options This screen allows modification of the options installed on the unit.
Settings:
Changeable Digital
Inputs
This screen allows modification of the changeable digital inputs.
FAN : ST: Fantype is ON/OFF fans
: INV: Fantype is a combination of ON/OFF fans and Inverter fans
VA:N/Y : Select if Volt-Ampere meters (option) is installed.
When Y is selected, an additional screen will appear in the readout
menu.
2PUMP:Y/N : Select if 2nd pump is installed
HEATERTAPE:Y/N : Select if heatertape is installed
CONFIRM? : • Confirm settings, when an option setting has been changed.
When a setting has been changed without confirmation
the
0UA: OP. NOT CONFIRMED alarm will be displayed and can
only be reset after confirmation.
• When a main PCB has been changed or reprogrammed with
new software, the OU4: OP. NOT CONFIRMED will be dis-
played and can only be reset after confirmation.
_v
HEATERTAPE:N
FAN:ST
UNIT OPTIONS
CONFIRM? N
VA:N 2PUMP:N
_ CHANG. INP/OUTPUTS
DI1:NONE
DI2:NONE
DI3:NONE
