ESIE06-05 General Outline
Part 1 – System Outline 1–9
3
1
4
5
1.4 Technical Specifications for options: EWAQ130-150DAYN
Technical
specifications
The table below contains the technical specifications for the options of the EWAQ130-150DAYN.
Technical specifications options
OPSP
Units EWAQ130DAYN* EWAQ150DAYN*
Weight Additional machine weight kg 250 250
Additional operation weight kg 286 286
Additional gross weight kg 250 250
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP65-230/2 TP65-230/2
Nominal Static Height Unit kPa 134 126
Hydraulic components Additional unit water volume l 36 36
Expansion vessel l 35
Pre-charge pressure exp. vessel bar 1,5
Safety valve bar 3
OPSP + OPBT
Units EWAQ130DAYN* EWAQ150DAYN*
Weight Additional machine weight kg 300 300
Additional operation weight kg 526 526
Additional gross weight kg 300 300
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP65-230/2 TP65-230/2
Nominal Static Height Unit kPa 134 126
Hydraulic components Buffer tank l 190 190
Additional unit water volume l 226 226
Expansion vessel l 35
Pre-charge pressure exp. vessel bar 1,5
Safety valve bar 3
OPHP
Units EWAQ130DAYN* EWAQ150DAYN*
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP65-340/2 TP65-340/2
Nominal Static Height Unit kPa 253 248
