ESIE06-05 The Digital Controller For Multiscroll Chillers

Part 2 – Functional Description 2–69

2.15.5 EEV

This menu allows modification of the EEV settings. The EEV parameter values used in the following

screens are not the same for all units. Each unit has his own parameters and should not been

changed.

EEV Control This screen allows modification of the EEV additional screen setting.

Setting:

EEV Control Steps This screen allows modification of the EEV step pulses.

Settings:

SCREENS : Used to select whether the additional EEV screens in the Readout

menu have to be displayed or not. (C1/C2 Temp readout screen)

SCREENS: N

EEV CONTROL

■ STEP RANGE : Upper limit of max. opening pulses of EV ( o~2625 pls)

■ INITIAL STEP : Open- closing steps during initialisation process at power-on

■ ALL CLOSED ADD : Additional pulses added to the close pulses.

Close pulses at power on: 2625 + 160 = 2785

Close pulses at compressor stop: current output pulses + 160

STEP RANGE:2625pls

INITIAL STEP:0132pls

ALL CLOSE ADD:160pls

EEV CONTROL
