Daikin EWYQ130DAYN [268/524] Defrost normal
![Daikin EWAQ240DAYN [268/524] Defrost normal](/views2/1657857/page268/bg10c.png)
The Digital Controller For Multiscroll Chillers ESIE06-05
2–42 Part 2 – Functional Description
3
1
2
4
5
Defrost Timer This screen allows modification of the minimum time between 2 defrost cycles of the same circuit.
Settings:
2.8.12 Service Menu
Operational
information
The service menu is accessible through the last screen of the user settings menu. To enter the service
menu you need the service password. Please contact your distributor for this password. It is only
possible to access the service menu when the unit is “OFF”. Only a qualified engineer is allowed to
access this menu.
You need the password to access this menu.
MIN. TIME BETWEEN
DEFROST
: Minimum time between 2 defrost cycles of the same circuit
in order to keep heating capacity and prevent frequent
defrosting.
NORMAL : Normal start value, default 30 min, (range 20~120 min)
SHORT : Short start value, default 10min, (range 1~20min)
DEFROST_^
MIN. TIME BETWEEN
DEFROST: NORMAL
ENTER SERVICE
PASSWORD:0000
TO LOGIN
