Daikin EWYQ130DAYN [170/524] Pcb i o overview fuses
![Daikin EWYQ130DAYN [170/524] Pcb i o overview fuses](/views2/1657857/page170/bgaa.png)
Wiring Layout ESIE06-05
1–158 Part 1 – System Outline
3
11
4
5
3.4.4 PCB I/O overview & fuses
Main PCB (A11P)
X12A (1-3-5) DI: Reverse phase detection (L1-L2-L3) c1
X4A DI: High pressure switch c1
X5A DI: Compressor interclock 1 c1
X6A DI: Compressor interlock 2 c1
X7A DI: Fan overcurrent relay Fanstep 1 c1
X8A DI: Fan overcurrent relay Fanstep 2 c1
X9A DI: Fan overcurrent relay Fanstep 3 c1
X27A DI: Fan inv safety c1 (only for OPIF)
X29A (3-4) not used
X30A DI: Flow switch
X31A DI: Pump interlock
X32A (3-4) Ch DI 1: function not pre-defined
X32A (1-2) Ch DI 2: function not pre-defined
X13A DO: Compressor contactor 1 c1
X14A DO:Compressor contactor 2 c1
X15A DO: Heatertape
X16A DO: Pump contactor
X17A DO: Reverse valve c1 (Only for EWYQ)
X19A (1-3) DO: Fanstep 1 c1
X19A (5-7) DO: Fanstep 2 c1
X20A DO: Fanstep 3 c1
X22A Ch DO1: “SAFETY + W. (NO)” (def)
X24A Ch DO2: “GEN. OPERATION” (def)
X25A Ch DO3: function not pre-defined
X33A AI: Ambient sensor
X34A AI: Inlet water sensor
X35A AI: Outlet water sensor
X36A AI: Suction temperature sensor c1
X37A AI: Refrigerant piping temperature sensor c1
X38A AI: Coil temperature sensor 1 c1 (only for EWYQ)
X39A AI: Coil temperature sensor 2 c1 (only for EWYQ)
X40A AI: Discharge temperature sensor 1 c1
