ESIE06-05 The Digital Controller For Multiscroll Chillers

Part 2 – Functional Description 2–25

2.7 Set Points Menu

Screen: password Depending on the settings in the user settings menu explained further on, you may need the user

password to be able to enter the screens in this menu.

This screen will only appear if a password is required.

Remark: The units leave the factory with the user password set to "1234". This user password can be

modified in the user password menu.

Setpoint Screen This menu allows you to set the inlet/outlet water temperature of the evaporator/condenser of setpoint

1 and 2. These set points will not be active in the Manual Control Mode.

A " >" symbol is displayed in front of the active setpoint in this screen.

Remark: You can select setpoint 1 or 2 with a digital input from a switch. In the service menu you can

select which digital input you want to use for this.

ENTER PASSWORD

PASSWORD: 0000

TO LOGIN

Display Description

COOL setpoints in cooling mode

HEAT setpoints in heating mode

INLSP inlet water temp. setpoint 1

INLSP inlet water temp. setpoint 2 (dual setpoint)

OUTSP outlet water temp. setpoint 1

OUTSP outlet water temp. setpoint 2 (dual setpoint)

COOL. OUTSP1:007.0 °C

COOL. OUTSP2:007.0 °C

COOL. INLSP1:012.0 °C

COOL. INLSP2:012.0 °C
