General Outline ESIE06-05
1–6 Part 1 – System Outline
3
11
4
5
Air Heat
Exchanger
Type Cross fin coil / Hi-Xss tubes and PE coated
Rows 2 2 3 3 3 3 3 3
Stages 56 56 48 56 56 56 48 48
Fin Pitch mm 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8
Face Area m2 2.46 2.46 2.11 2.46 3.02 3.02 2.11 2.11
No. of Coils 4 4 4 4 4 4 8 8
Hydraulic Com-
ponents
Unit water volume l 15 15 17 19 25 27 39 42
Nominal water
pressure drop unit
kPa6667646372798385
Fan Drive Direct drive
Nominal air flow m3/min 780 780 800 860 1290 1290 1600 1600
Model Quantity 4 4 4 4 6 6 8 8
Speed rpm 880 880 900 970 970 970 900 900
Motor
Out-
put
W 500 500 600 1000 1000 1000 600 600
Discharge direc-
tion
Vertical
Compressor Type Scroll compressor
Refrigerant oil type Daphne FVC68D
Refrigerant oil
charge
l 6.7 6.7 3.3 6.7 6.7 6.7 6.7 6.7
Model Quantity 2 2 4 4 2 4 2 4
Model SJ180 SJ240 SJ161 SJ180 SJ180 SJ240 SJ240 SJ300
Speed rpm 2900 2900 2900 2900 2900 2900 2900 2900
Quantity 22
Model SJ240 SJ300
Speed rpm 2900 2900
Sound Level Sound
Power
Cool-
ing
dBA8686888990919191
Refrigerant circuit Refrigerant type
R-410A
Refrigerant charge kg 33 33 19 25 29 28 39 39
kg 19 25 39 39
No of circuits 1 1 2 2 2 2 2 2
Refrigerant control Electronic expansion valve
Piping connec-
tions
Water heat exchanger inlet /
outlet
3” OD 3” OD 3” OD 3” OD 3” OD 3” OD 3” 3”
Water heat exchanger drain 1/2” G
EWAQ080DA
YN
EWAQ100DA
YN
EWAQ130DA
YN
EWAQ150DA
YN
EWAQ180DA
YN
EWAQ210DAY
N
EWAQ240DA
YN
EWAQ260DA
YN
