Functional Control for a Standalone Unit ESIE06-05
2–126 Part 2 – Functional Description
3
1
2
4
5
Fanstep output for 30-40 Hp and 90-100 Hp units. Circuit 2 is not present with 30-40Hp units.
K14F
K24F
K13F
K23F
K15F
K25F
K16F
K26F
Fanstep
20 Hz
30 Hz
45 Hz
50 Hz
20 Hz
30 Hz
45 Hz
50 Hz
20 Hz
30 Hz
45 Hz
50 Hz
20 Hz
30 Hz
45 Hz
50 Hz
OFF
OFF
OFF
OFF
ON
ON
ON
ON
OFF
OFF
OFF
OFF
ON
ON
ON
ON
120
30
45
50
70
80
95
100
%
2
3
4
5
6
7
8
Changeover
on/off fan &
Fan inv
