AXIOMET AX-EL300W60A [2/72] Function features

All “electronic load” and “load” appear in this manual refer to this Series Electronic Load if there is no

special explanation.

2.1. Function Features

- 4 basic functions: CC, CV, CR and CP; 9 basic test modes: CCL, CCH, CVL, CVH, CRL, CRM, CRH, CPV,

CPC;

- The 24 bit A/D and 16 bit D/A converters incorporated, provide this equipment with greatly enhanced

setting and measurement resolution. 40kHz D/A conversion rate fully improves high-speed performance;

- Perfect protection assures high reliability in the most complicated of test environments;

- Innovative design of CPV and CPC modes effectively improves the practicability of CP mode;

more complex test procedures;

- The input binding posts with their innovative design are especially suitable for large current testing;

- Provides short-circuit test, battery discharge test and other auxiliary functions;

- A high-efficiency, intelligent cooling system can effectively reduce system temperature and enhance power

density;

- Automatic ON/OFF function simplifies test operation;

- Knobs and digital keypad makes the operation more convenient;

- Save/recall function can save multiple groups of general settings;

- Supports SCPI (Standard Commands for Programmable Instrumentation) and Labview, and provides

necessary PC software;
