3 /// Use “↑”, “↓” keys to select the menu item “Function”. Use Entry keys or the knob to select the param-

eter “Tran”, and press “Enter” key to confirm. /// Trig Func 0 Tran

4 /// Press “Cancel” key to exit the main menu. ///

For the above operating procedures, the corresponding SCPI commands should be:

TRIG:FUNC TRAN ; Selects transient operation (TRAN) for trigger function

5.13.7. Knob Function

Example: Enable the knob function.

Procedures /// Operation Descriptions /// Display

1 /// Press “Menu” key to enter into the selectable menu. /// MENU 0 SYST

Example: Enable the key sound.

Procedures /// Operation Descriptions /// Display

1 /// Press “Menu” key to enter into the selectable menu. /// MENU 0 SYST

2 /// Use Entry keys or the knob to select “1 Config”, press “Enter” key to confirm and enter into Config.

/// MENU 1 CONF

3 /// Use “↑”, “↓” keys to select the menu item “Key Sound”. Use Entry keys or the knob to select the

parameter “On”, and press “Enter” key to confirm. /// KEY SO 1On

4 /// Press “Cancel” key to exit the main menu. ///

5.13.9. Communication Interface

Example: Select RS232 interface; set the baud rate to 9600; set parity check to None; set data bit to 8; set

parameter “9600”, and press “Enter” key to confirm. /// BAUD R 2 9600

4 /// Use “↑”, “↓” keys to select the menu item “Parity Check”. Use the knob to select the parameter “None”,

and press “Enter” key to confirm. /// PARITY 0 None
