2.7. Menus

2.7.1. Main Menus

Press “Menu” key to enter into main menu and the LCD dispays the selectable menus. Rotate knob to

select menu. Press “Enter” key to enter into the function option on the cursor. Use “↑” key or “↓” key to

turn over the LCD screen. At this time, press “↓” key to enter into the next level submenu. Press “Cancel”

key to exit the menu setting.

System Set

/// CC SET /// Set CC mode range

/// CV SET /// Set CV mode range

/// CR SET /// Set CR mode range

/// CP SET /// Set CP mode range

/// VON LAtch /// Von volgate latch

/// VON POint /// Set Von voltage point

/// VOFF Point /// Set Voff voltage point

/// CV CURr limit /// Current limit in CV mode

/// CURR Rise rate /// Current rise rate in CC mode

/// CURR Fall rate /// Current fall rate in CC mode

/// SHORT /// Short circuit mode

Config

/// LOAD Default /// Restore default

/// INPUT recall /// Set the power-on input status as last power-off status

/// POWER on recall /// Set the power-on relative parameters as last power-off settings

/// KNOB /// Enable knob function

/// KEY SOund /// Enable key sound

/// BAUD Rate /// Baud rate setting

/// PARITY check /// Parity check setting

/// DATA Bit /// Data bit

/// STOP bit /// Stop data bits

/// ADDRESs /// Instrument’s ID or address

/// SAVE /// Store parameters

/// RECALL /// Recall parameters

/// ERROR /// Error message

Protection

/// OCP STate /// Overcurrent protection On/Off

/// OCP LEvel /// Current preotection limit

/// OCP DElay /// Delay time to turn off the load in OCP

/// OVP LEvel /// Voltage preotection limit

/// OPP LEvel /// Power preotection limit

/// OPP DElay /// Delay time to turn off the load in OPP
