Defort DDT-1400A [6/48] Maintenance safety precaution

SET UP

Engine and main pipe

Align the hanger and the fuel tank, using attached 4

socket screws, secure the connection ﬁ rmly with equal

force.

Handle

Loosen the 4 bolts on the handle bracket.(F2)

Insert the right handle (throttle lever is attached) and

the left handle assembly into the bracket and retighten

the bolts securely.

SAFETY GUARD

Attach the safety guard to the gear case and ﬁ x it with

the clump and 2 bolts (M5*25) securely.

Throttle wire

WARNING! After ﬁ tting up the wire, make

sure that the throttle cable is put in the throttle

lever. If not, it is veiy aangerous because the

engines rotate after releasing the throttle.

1. Hook the cable end into the hole of the throttle le-

ver. And set the cable in the lever as shown in the

picture.

2. Wrap the band so as the throttle wire is ﬁ xed with

the handle.

Adjusting the throttle cable

1. After releasing the throttle lever, pull the throttle

wire. The normal play is 1 or 2 mm when measured

at the carburetor side end.

2. If the play is short or long, take off the air cleaner

cover, loosen the lock nut and adjust the play.Ad-

just nut. Lock nut.

Installing the metal blade

1. Set the inner holder to the gear shaft, and turn to ﬁ x

with the attached L-shaped bar.

2. Put the blade on the inner holder with letters to

the gear case, and match correctly the hole of the

blade to the projection of the inner holder.

3. Set the outer holder to the gear shaft with the hol-

lowed face to the blade.

4. Put the attached bolt cover on the outer holder and

secure it with the bolt (left screw) together with the

spring washer and the washer.

Installing the nylon cutter

1. Set correctly the inner holder and the outer holder to

the gear shaft.

2. Screws the attached bolt (M8 Left) into the gear

shaft and secure it with the spanner.

3. Screw the nylon cutter into the bolt by ﬁ xing the in-

ner holder with the L-shaped bar and tighten it man-

ually.

NOTE Keep bolts and washers to install the

blade carefully so as not to lose them.

NOTES ON TRANSPORTATION

1. Make sure the appropriate blade cover is in place.

2. When transporting by car, ﬁ x the unit ﬁ rmly using

a rope. Do not transport by bicycle or motorcycle

because it is dangerous.

3. Never transport the brush cutter over rough roads

over long distances without ﬁ rst removing all fuel

from the fuel tank, as doing so might cause fuel to

leak from the tank.

OPERATION SAFETY PRECAUTIONS

1. Grip thе handles of the brush cutter ﬁ rmly with both

hands. If you suspend the work, place the throttle

into the idling position.

2. Always be sure to maintain a steady, even posture

while working.

3. Maintain the speed of the engine at the level re-

quired to perform cutting work, and never raise the

speed of the engine above the level necessary.

4. If the grass gets caught in the blade during opera-

tion, or if you need to check the unit or refuel the

tank, always be sure to turn off the engine.

5. If the blade touches a hard object like a stone, im-

mediately stop the engine and check if something

is wrong with the blade. If so, replace the blade by

new one.

6. If someone calls out while working, always be sure

to turn off the engine before turning around.

7. Never touch the spark plug or plug cord while the

engine is in operation. Doing so may result in being

subjected to an electrical shock.

8. Never touch the mufﬂ er, spark plug, or other metal-

lic parts of the engine while the engine is in opera-

tion or immediately after shutting down the engine.

Doing so may result in serious burns.

9. When you ﬁ nish cutting in one location and wish to

continue work in another spot, turn off the engine

and turn the unit as the blade faces away from your

body.

MAINTENANCE SAFETY PRECAUTION

1. Perform the maintenance and checking opera-

tions described in this manual at regular intervals.

If any parts must be replaced or any maintenance

or repair work not described in this manual must

be performed, please contact a representative from

the store nearest authorized servicing dealer for as-

sistance.

2. Under no.circumstances should you ever take

apart the brush cutter or after it in any way. Doing

so might result in the brush cutter becoming dam-

aged during operation or the brush cutter becoming

unable to operate properly.

3. Always be sure to turn off the engine before per-

forming any maintenance or checking procedures.

4. When sharpening, removing, or reattaching the

blade proper tools and equipment to prevent injury.

5. When replacing blade or any other parts or when

replacing the oil or any lubricants, always be sure

to use only products or products which have been

certiﬁ ed by for use with the brush cutter.
