Gigabyte MJ11-EC0 (rev. 1.2) [15/109] 6 internal connectors

- 15 - Hardware Installation

1-6 Internal Connectors

Read the following guidelines before connecting external devices:

•

First make sure your devices are compliant with the connectors you wish to connect.

•

Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

•

After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1) P12V_AUX1 11) PMBUS

2) DC_IN1 12) F_USB3

3) SATA0 13) COM1

4) SATA1 14) BP_1

5) SATA2 15) IPMB

6) SATA3 16) FP_1

7) SGPIO1 17) 80H

8) CPU0_FAN 18) BAT

9) SYS_FAN1

10) SYS_FAN2

DIMM_P0_A0

DIMM_P0_A1

DIMM_P0_B0

DIMM_P0_B1

CPU

18 15

23456891012
