BIOS Setup - 64 -

2-2-14 T1s Auth Conguration

Parameter Description

ServerCAConguration

Press[Enter]forcongurationofadvanceditems.



Enroll Cert

–Press[Enter]toenrollacerticate

• Enroll Cert Using File

• Cert GUID

Input digit character in 1111111-2222-3333-4444-1234567890ab

format.

– Commit Changes and Exit

– Discard Changes and Exit



Delete Cert

ClientCertConguration

Press[Enter]forcongurationofadvanceditems.
