- 39 - BIOS Setup

2-2-6 CPU Conguration

Parameter

Description

SVM Mode

Enable/Disable the CPU Virtualization.

Options available: Enabled, Disabled. Default setting is Enabled.

SMEE

Controls the Secure Memory Encryption Enable (SMEE) function.

Options available: Enabled, Disabled. Default setting is Enabled.

Node 0 Information

Press [Enter] to view the memory information related to Node 0.
