Gigabyte MJ11-EC0 (rev. 1.2) [35/109] 2 4 s5 rtc wake settings

- 35 - BIOS Setup

2-2-4 S5 RTC Wake Settings

Parameter

Description

Wake System from S5

(Note)

Enable/Disable system wake on alarm event.

Options available: Disabled, Fixed Time, Dynamic Time. When Fixed Time is

selected,systemwillwakeonthehr::min::secspecied.

Default setting is Disabled.

(Note) Advanceditemspromptwhenthisitemisdened.
