- 85 - BIOS Setup
2-6 Boot Menu
The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error
messageifthelegacydrive(s)speciedisnotbootable.
Parameter
Description
BootConguration
Setup Prompt Timeout
Number of seconds to wait for setup activation key. 65535 (0xFFFF)
meansindenitewaiting.
Press the numeric keys to input the desired values.
Bootup NumLock State
Enable/Disable the Bootup NumLock function.
Options available: On, Off. Default setting is Off.
Quiet Boot
Enable/Disable showing the logo during POST.
Options available: Enabled, Disabled. Default setting is Enabled.
FIXED BOOT ORDER
Priorities
Boot Option #1 / #2 / #3 / #4 /
#5
Press[Enter]tocongurethebootpriority.
By default, the server searches for boot devices in the following
sequence:
1. Hard drive.
2. CD-COM/DVD drive.
3. USB device.
4. Network.
5. UEFI.
