Gigabyte MJ11-EC0 (rev. 1.2) [51/109] 2 11 3 umc common options

- 51 - BIOS Setup

2-2-11-3 UMC Common Options

Parameter Description

UMC Common Options

DDR4 Common Options Press[Enter]forcongurationofadvanceditems.

DRAM Memory Mapping Press[Enter]forcongurationofadvanceditems.

Memory MBIST Press[Enter]forcongurationofadvanceditems.
