Gigabyte MJ11-EC0 (rev. 1.2) [46/109] 2 11 amd cbs

BIOS Setup - 46 -

2-2-11 AMD CBS

Parameter

Description

AMD CBS

Zen Common Options

Press[Enter]forcongurationofadvanceditems.

DF Common Options

Press[Enter]forcongurationofadvanceditems.

UMC Common Options

Press[Enter]forcongurationofadvanceditems.

NBIO Common Options

Press[Enter]forcongurationofadvanceditems.

FCH Common Options

Press[Enter]forcongurationofadvanceditems.

NTB Common Options

Press[Enter]forcongurationofadvanceditems.
