- 81 - BIOS Setup
2-5 Security Menu
The Security menu allows you to safeguard and protect the system from unauthorized use by setting up
access passwords.
There are two types of passwords that you can set:
• Administrator Password
Entering this password will allow the user to access and change all settings in the Setup Utility.
• User Password
Entering this password will restrict a user’s access to the Setup menus. To enable or disable
thiseld,aAdministratorPasswordmustrstbeset.Ausercanonlyaccessandmodifythe
SystemTime,SystemDate,andSetUserPasswordelds.
Parameter
Description
Administrator Password
Press[Enter]toconguretheadministratorpassword.
User Password
Press[Enter]toconguretheuserpassword.
Secure Boot
Press[Enter]tocongureadvanceditems.
