Gigabyte MJ11-EC0 (rev. 1.2) [23/109] 7 jumper settings

- 23 - Hardware Installation

1-7 Jumper Settings

Jumper Name Jumper Setting

Clear CMOS

1-2: Normal operation. (Default)

2-3: Clear CMOS data.

Clear CMOS

CLR_CMOS

Default

Enable
