BIOS Setup - 52 -
2-2-11-3-1 DDR4 Common Options
Parameter Description
DDR4 Common Options
DRAMTimingConguration
Press [Enter] to enable / disable restrictions for DDR4 frequency and
voltage programming. Memory speeds will be capped at AMD guidelines.
I Decline
I Accept
– Overclock: Enable/Disable Memory Overclock Settings.
– Options available: Auto, Enabled. Default setting is Auto.
DRAMControllerConguration
Press[Enter]forcongurationofadvanceditems.
DRAM Power Options
– Power Down Enable
»
Enable/Disable DDR power down mode.
»
Options available: Auto, Enabled, Disabled. Default setting is
Auto.
Cmd2T
– Selects the Cmd2T mode on ADDR/CMD.
– Options available: Auto, 1T, 2T. Default setting is Auto.
Gear Down Mode
– Enable/Disable the Gear Down Mode function.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
