- 53 - BIOS Setup
Parameter Description
DataBusConguration
Press[Enter]forcongurationofadvanceditems.
DataBusCongurationUserControls
– SpeciesthemodefordrivestrengthtoAutoorManual.
– Options available: Auto, Manual. Default setting is Auto.
Common RAS
Press[Enter]forcongurationofadvanceditems.
Data Poisoning
– Enable/Disable the Data Poisoning function.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
RCD Parity
– Enable/Disable the RCD Parity function.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
DRAM Address Command Parity Retry
– Enable/Disable the DRAM Address Command Parity Retry function.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
Max Parity Error Replay
– CongurestheMaxParityErrorReplay.(0~0x3
f).
– Default setting is 8.
– Please note that this item is congurable when DRAM Address
Command Parity Retry is set to Enabled.
Write CRC Enable
– Enable/Disable the Write CRC function.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
DisableMemoryErrorInjection
– Options available: False, True. Default setting is True.
ECCConguration
– DRAM ECC Symbol Size
»
CongurestheDRAMECCSymbolSize.
»
Options available: Auto, x4, x8. Default setting is Auto.
– DRAM ECC Enable
»
Enable/Disable DRAM ECC. When set to Auto, it will set ECC to
enable.
»
Options available: Auto, Enabled, Disabled. Default setting is
Auto.
Security
Press[Enter]forcongurationofadvanceditems.
TSME
– Enable/Disable transparent secure memory encryption.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
Data Scramble
– Enable/Disable Data Scrambling.
– Options available: Auto, Enabled, Disabled. Default setting is Auto.
