Gigabyte MJ11-EC0 (rev. 1.2) [33/109] 2 3 ast2500 super io configuration

- 33 - BIOS Setup

2-2-3 AST2500 Super IO Conguration

Parameter

Description

AST2500 Super IO

Conguration

Super IO Chip Displays the super IO chip information

SerialPort1Conguration Press[Enter]forcongurationofadvanceditems.
