- 57 - BIOS Setup
Parameter
Description
PSI
Enable/Disable PSI.
Options available: Auto, Disable. Default setting is Auto.
ACS Enable
Enable/Disable ACS support.
Options available: Auto, Enable, Disabled. Default setting is Auto.
PCIe ARI Support
Enable/Disable Alternative Routing-ID Interpretation.
Options available: Auto, Enable, Disable. Default setting is Auto.
CLD0_VDDP Control Options available: Auto, Manual. Default setting is Auto.
HD Audio Enable
Enable/Disable HD Audio.
Options available: Auto, Enable, Disabled. Default setting is Auto.
Block PCIe Loopback
Enable/Disable the Block PCIe loopback mode for hot plug slots.
Options available: Auto, Enable, Disable. Default setting is Auto.
CRS Delay Set the CRS delay for hot plug ports.
CRS Limit Set the CRS limit for hot plug ports.
HotPlugags
Press[Enter]forcongurationofadvanceditems.
Ignore sideband
– Enable/Disable the sideband function.
– Options available: Auto, Enabled, Disabled. Default setting is
Disabled.
Disable L1 w/a
– Enable/Disable the L1 w/a function.
– Options available: Auto, Enabled, Disabled. Default setting is
Disabled.
Disable BridgeDis
– Enable/Disable BridgeDis update based on sideband.
– Options available: Auto, Enabled, Disabled. Default setting is
Disabled.
Toggle RRC Enable
– Enable/Disable Toggle RRC during hot plug events.
– Options available: Auto, Enabled, Disabled. Default setting is
Disabled.
Toggle RRC Enable
– Enable/Disable register control of BridgeDis only follows DL_Active.
– Options available: Auto, Enabled, Disabled. Default setting is
Disabled.
