Русский
104 105
Fatal1ty X99 Professional/3.1 Series
* При установке модуля Ultra M.2 PCI Express слот PCIE3
будет отключен.
• 1 x гнездо half mini-PCI Express:
• поддержка AMD Quad CrossFireX
TM
, 4-Way
CrossFireX
TM
, 3-Way CrossFireX
TM
и CrossFireX
TM
• поддержка NVIDIA® Quad SLI
TM
, 4-Way SLI
TM
, 3-Way
SLI
TM
и SLI
TM
* При установке центрального процессора, имеющего 28
линий, 4-Way CrossFireX
TM
и 4-Way SLI
TM
не
поддерживаются.
Аудио
• 7.1-канальный звук высокой четкости HD Audio с
защитой данных (аудиокодек Realtek ALC1150)
• Поддержка Premium Blu-ray Audio
• Защита от перенапряжения (ASRock Full Spike
Protection)
• Поддержка Purity Sound™ 2
- Конденсаторы для аудиосистем серии Nichicon Fine
Gold
- 115 дБ SNR DAC с дифференциальным усилителем
- Усилитель TI® NE5532 Premium Headset Amplier
(поддержка гарнитуры с сопротивлением до 600
Ом)
- Технология Direct Drive
- Крышка с экранированием от электромагнитных
помех
- Изолирующее экранирование печатной платы
• Поддержка DTS-подключения
ЛВС
• 1 x Intel® I218V (Gigabit LAN PHY 10/100/1000 Mb/s)
• 1 x Qualcomm® Atheros® Killer
TM
E2200 (PCIE x1 Giga-
bit LAN 10/100/1000 МБ/с)
• Supporta la tecnologia Qualcomm® Atheros® Security
Wake On Internet Technology (в Qualcomm® Atheros®
Killer
TM
E2200)
• Поддержка Wake-On-LAN
• Молниезащита и защита электростатического
напряжения (ASRock Full Spike Protection)
• Поддержка Energy Ecient Ethernet 802.3az
• Поддержка PXE
Порты ввода-
вывода на
задней панели
• 1 x PS/2 для мыши/клавиатуры
• 1 x оптический выходной SPDIF
• 1 x Порт для мыши Fatal1ty (USB 2.0) с защитой от
электростатического напряжения (ASRock Full Spike
Protection)
• 1 x Порты USB 2.0 с защитой от электростатического
напряжения (ASRock Full Spike Protection)
