日本語
180 181
Fatal1ty X99 Professional/3.1 Series
LN2 モードスイッチ
(LN2MODE)
（p.1、No. 13 参照）
液体窒素冷却を使用
して究極のオーバーク
ロックをする際に、LN2
モードで、プロセッサ内
のコ ー ルドブ ートバグ
の問題を解消します。
ダイレクトキ ーボタン
(DIRKEY1)
（p.1、No. 31 参照）
ダイレクトキ ーボタン
は、ユーザーがシステ
ム電源をオン にして、
UEFI 設定画面に直接
入力することを可能に
します。
ON
OFF
