![ASRock Fatal1ty X99 Professional/3.1 [205/224] Fatal1ty x99 professional 3 series](/img/pdf.png)
ASRock Fatal1ty X99 Professional/3.1 [205/224] Fatal1ty x99 professional 3 series
![ASRock Fatal1ty X99 Professional/3.1 [205/224] Fatal1ty x99 professional 3 series](/views2/1686125/page205/bgcd.png)
繁體中文
200 201
Fatal1ty X99 Professional/3.1 Series
• 1 x 半迷你 PCI Express 插槽
• 支援 AMD Quad CrossFireX
TM
, 4-Way CrossFireX
TM
, 3-Way
CrossFireX
TM
和 CrossFireX
TM
技術
• 支援 NVIDIA® Quad SLI
TM
, 4-Way SLI
TM
, 3-Way SLI
TM
和
SLI
TM
技術
* 若安裝 28 條通道的 CPU，將不支援 4-Way CrossFireX
TM
與 4-Way SLI
TM
。
音訊
• 7.1 CH HD 音訊含內容保護（Realtek ALC1150 音訊轉碼
器）功能
• 高階藍光音訊支援
• 支援防突波 ( 華擎全防護 )
• 支援天籟美聲二代
- Nichicon Fine Gold 系列音效專用電容
- 115dB SNR DAC 與差分放大器
- TI® NE5532 高級耳機放大器（支援最高可達 600 Ohms
的耳機）
- 直接驅動技術
- EMI 屏蔽蓋
- PCB 隔離屏蔽
• 支援 DTS Connect
LAN
• 1 x Intel® I218V (Gigabit LAN PHY 10/100/1000 Mb/s)
• 1 x Qualcomm® Atheros® Killer
TM
E2200 系列 (PCIE x1 Giga-
bit LAN 10/100/1000 Mb/s)
• 支援 Qualcomm® Atheros® Security Wake On Internet 技術
( 使用 Qualcomm® Atheros® Killer
TM
E2200 系列 )
• 支援網路喚醒
• 支援防雷擊 / 防 ESD 靜電 ( 華擎全防護 )
• 支援 Energy Ecient Ethernet 802.3az
• 支援 PXE
後面板 I/O
• 1 x PS/2 滑鼠／鍵盤連接埠
• 1 x 光纖 SPDIF 輸出連接埠
• 1 x Fatal1ty 滑鼠連接埠 (USB 2.0)（支援防 ESD 靜電（華
擎全防護））
• 1 x USB 2.0 連接埠（支援防 ESD 靜電 ( 華擎全防護 )）
