146 147
Fatal1ty X99 Professional/3.1 Series
1.5 Akıllı Anahtar
Anakartta onbir adet akıllı düğme bulunur: Güç Düğmesi, Sıfırlama Düğmesi, CMOS
Düğmesini Temizleme, Hızlı OC Düğmeleri, Menü Düğmesi, PCIe AÇ/KAPAT
Düğmesi, Yavaş Modu Düğmesi, BIOS Seçimi Düğmesi, LN2 Modu Düğmesi ve
Direkt Tuş Düğmesi.
Güç Düğmesi
(PWR)
(bkz. sf.1, No. 34)
Güç Düğmesi, kullanıcıların
sistemi hızlı bir şekilde açıp
kapatmalarını sağlar.
Sıfırlama Düğmesi
(RST)
(bkz. s.1, No. 35)
Sıfırlama Düğmesi
kullanıcıların sistemi hızlı bir
şekilde sıfırlamalarını sağlar.
CMOS Temizleme Düğmesi
(CLRCBTN1)
(bkz. sf.4, No. 13)
CMOS Temizleme Düğmesi
kullanıcıların CMOS
değerlerini hızlı bir şekilde
temizlemelerini sağlar.
+ / - Hızlı OC Düğmeleri
(MINUS:bkz. sf.1, No. 10)
(PLUS:bkz. sf.1, No. 9)
+ / - Hızlı OC Düğmeleri kul-
lanıcıların Hızlı OC'deki OC
frekansını hızla ve kolayca
ayarlamalarını sağlar.
Menü Düğmesi
(MENU:bkz. sf.1, No. 11)
MENÜ Düğmesi kul-
lanıcıların, gösterilen
Tarih/Saat, Sıcaklık ve Voltaj
bilgileri arasında hızla geçiş
yapmalarını sağlar.
Power
Reset
Bu işlev yalnızca bilgisayarınızı kapattığınızda ve şini prizden çektiğinizde çalışır.
Bu hız aşırtma davranışı, bellek kapasitesi, termal solüsyon vb. gibi sistem yapılandırmasına
bağlıdır. Hız aşırtma sisteminizin kararlılığını etkileyebilir, hatta bileşenler ve cihazlarda
hasara neden olabilir. Hız aşırtmadan doğabilecek zararlar konusunda sorumlu olmayacağız.
+
-
MENU
