72 73
Fatal1ty X99 Professional/3.1 Series
* Se il modulo PCI Express M.2 è installato, verrà disattivato lo
slot PCIE3.
• 1 slot half mini-PCI Express
• Supporto di AMD Quad CrossFireX
TM
, 4-Way CrossFireX
TM
,
3-Way CrossFireX
TM
e CrossFireX
TM
• Supporto di NVIDIA® Quad SLI
TM
, 4-Way SLI
TM
, 3-Way
SLI
TM
e SLI
TM
* Se si installa una CPU a 28 corsie, non sono supportati 4-Way
CrossFireX
TM
e 4-Way SLI
TM
Audio
• Audio HD a 7.1 canali con Content Protection (codec audio
Realtek ALC1150)
• Supporto audio Blu-ray Premium
• Supporto protezione da sovratensione (protezione completa
ASRock dai picchi di corrente)
• Supporto di Purity Sound™ 2
- Cappucci audio Nichicon serie Fine Gold
- 115dB SNR DAC con amplicatore dierenziale
- TI® NE5532 Premium Headset Amplier (supporta cue
no a 600 Ohm)
- Tecnologia Direct Drive
- Copertura schermata EMI
- Schermatura isolata PCB
• Supporta DTS Connect
LAN
• Gigabit LAN 10/100/1000 Mb/s
• Giga PHY Intel® I218V
• 1 x Serie Qualcomm® Atheros® Killer
TM
E2200 (PCIE x1
Gigabit LAN 10/100/1000 Mb/s)
• Supporta la tecnologia Qualcomm® Atheros® Security Wake
On Internet Technology (sulla serie Qualcomm® Atheros®
Killer
TM
E2200)
• Supporta Wake-On-LAN
• Supporto la protezione da fulmini/scariche elettrostatiche
(ESD) (protezione completa ASRock dai picchi di corrente)
• Supporta Energy Ecient Ethernet 802.3az
• Supporta PXE
I/O pan-
nello
posteriore
• 1 x porta mouse/tastiera PS/2
• 1 x porta uscita SPDIF ottico
• 1 x Porta mouse Fatal1ty (USB 2.0) (supporto protezione da
scariche elettrostatiche (ESD) (protezione completa ASRock
dai picchi di corrente))
