한 국 어
152 153
Fatal1ty X99 Professional/3.1 Series
* Ultra M.2 PCI Express 모듈이 설치된 경우 , PCIE3 슬롯을 사
용할 수 없습니다 .
• 하프 mini-PCI Express 슬롯 1 개
• AMD Quad CrossFireX
TM
, 4 웨이 CrossFireX
TM
, 3 웨이
CrossFireX
TM
및 CrossFireX
TM
지원
• NVIDIA® Quad SLI
TM
, 4 웨이 SLI
TM
, 3 웨이 SLI
TM
및 SLI
TM
지
원
* 28 개 레인의 CPU 를 설치하면 4-Way CrossFireX
TM
및
4-Way SLI
TM
가 지원되지 않습니다 .
오디오
• 콘텐츠 보호를 이용한 7.1 CH HD 오디오 지원 (Realtek
ALC1150 오디오 코덱 )
• 프리미엄 Blu-ray 오디오 지원
• 서지 보호 지원 (ASRock 풀 스파이크 보호 )
• Purity Sound ™ 2 지원
- Nichicon Fine Gold 시리즈 오디오 캡
- 디퍼렌셜 증폭기 포함 115dB SNR DAC
- TI® NE5532 프리미엄 헤드셋 증폭기 ( 최대 600 옴 헤드셋
지원 )
- 다이렉트 드라이브 기술
- EMI 차폐 커버
- PCB 절연 차폐
• DTS 연결 지원
LAN
• Intel® I218V 1 개 ( 기가비트 LAN PHY 10/100/1000 Mb/s)
• Qualcomm® Atheros® Killer
TM
E2200 시리즈 1 개 (PCIE x1
Gigabit LAN 10/100/1000 Mb/s)
• 인터넷 기술상 Qualcomm® Atheros® 시큐리티 웨이크
(Qualcomm® Atheros® Killer
TM
E2200 시리즈에 탑재 ) 지원
• Wake-On-LAN 지원
• 번개 /ESD 보호 지원 (ASRock 풀 스파이크 보호 )
• 절전형 이더넷 802.3az 지원
• PXE 지원
후면 패널
I/O
• PS 1 개 / 마우스 2 개 / 키보드 포트
• 광학 SPDIF 출력 포트 1 개
• Fatal1ty 마우스 포트 1 개 (USB 2.0)(ESD 보호 지원
(ASRock 풀 스파이크 보호 ))
