한 국 어
160 161
Fatal1ty X99 Professional/3.1 Series
(4 핀 ATX12V2)
(1 페이지 , 4 번 항목 참
조 )
*4- 핀 ATX 12V 전원 커넥
터는 마더보드에 추가 전
원을 공급하는 데 사용됩
니다 .
PCIe 전원 커넥터
(4 핀 PCIE_PWR1)
(1 페이지 , 43 번 항목 참
조 )
세 이상의 PCI Express 카드 설치
되어 있을 때 4 핀 몰렉스 전원 케
이블을 이 커넥터에 연결하십시
오 .
HDD 세이버 커넥터
(4 핀 SATA_PWR_1)
(1 페이지 , 28 번 항목 참
조 )
HDD 의 전원 상태를 관리하려면
HDD 세이버 케이블을 이 커넥터
에 연결하십시오 .
underbolt AIC 커넥터
(5 핀 TBT1)
(1 페이지 , 44 번 항목 참
조 )
underbolt ™ 확장 카드 (AIC) 를
설치할 때 5핀 신호 케이블 (GPIO
케이블 ) 을 이 커넥터에 연결하
십시오 .
* underbolt ™ AIC 카드를
PCIE3( 기본 슬롯 ) 에 설치하십
시오 .
시리얼 포트 헤더
(9 핀 COM1)
(1 페이지 , 42 번 항목 참
조 )
이 COM1 헤더는 시리얼
포트 모듈을 지원합니다 .
TPM 헤더
(17 핀 TPMS1)
(1 페이지 , 37 번 항목
참조 )
이 커넥터는 키 , 디지털 인증서 ,
암호 및 데이터를 안전하게 보관
할 수 있는 TPM(Trusted Platform
Module) 시스템을 지원합니다 .
TPM 시스템은 네트워크 보안을
강화하고 , 디지털 신원을 보호하
며 플랫폼 무결성을 유지합니다 .
1
+12V DETECT
GND
CCTS#1
RRTS#1
DDSR#1
DDTR#1
RRXD1
GND
TTXD1
DDCD#1
1
RRI#1
1
GN D
SMB_DATA_MAIN
LAD2
LAD1
GN D
S_PWRDWN #
SERIRQ #
GN
D
P CICL K
P CIRST #
LAD3
+3V
LAD0
+3VS B
GN D
FRAM E
SMB_CLK_MAIN
