66
Technical specications
Technical parameters are indicated on the appliance’s name
plate.
Admissible continuous operating time of the motor with
15 minutes
A break between successive uses 30 minutes
A break between successive turbo uses 10 seconds
The appliance’s noise level (L
WA
) 75 dB/A
Speed range I gear, II gear
The juice extractor type 477 is constructed in II class
insulation .
It does not require connection to the grounded socket.
ZELMER appliances meet the requirements of effective
standards.
The appliance meets the requirements of the following
directives:
Low Voltage Device (LVD) – 2006/95/EC. –
Electro-Magnetic Compatibility (EMC) – 2004/108/EC. –
The product is marked with CE symbol on the name plate.
Construction of the appliance (Fig. A)
1
Motor
a
power on/off button
b
gear 1 – gear 2 / turbo button
c
indicator light
d
pulse button (does not apply in case of juice extractor)
e
skimmer
f
sucker
g
power supplying cord
2
Juice container
h
spout
i
cover
3
Body of the juice collector
4
Strainer
5
Lid
6
Clamps
7
Pusher
8
Pulp container
Preparation of the juice extractor for
operation (disassembling) (Fig. B)
Before using the juice extractor for the rst time, disassemble
it and wash parts in contact with the processed product.
1
Place the juice extractor near the socket on the rm,
clean and dry surface.
2
Pull down the clamps (6) so that the tracks moved out of
grooves of the lid (5).
3
Take the pusher (7) and the lid (5) out.
4
Then remove the juice collector (2) including the body
(3) and the lter (4). To this end, turn the body (3) right
(clockwise) to the limit and raise the body with the juice
collector and the lter.
5
Finally, disassemble the juice collector (2) from the body (3).
Wash the disassembled parts (except the motor unit)
●
carefully in hot water and wash-up liquid. You can also
clean them in a dishwasher in max temp. 60°C (except
for the strainer and the motor unit). After drying them
carefully, start assembling the clean parts.
Preparation of the juice extractor for
operation (assembling) (Fig. C)
1
Put the body of the juice collector (3) on the motor unit
so that a clamp (6) is placed slightly on the left of the buttons
on the motor and turn left to the limit (anticlockwise) so that
a clamp is placed over the buttons.
2
Put the juice container (2) on the body (3) so that the lip
(h) was placed in the cutting of the body (3).
3
Put the lter (4) inside, press it slightly and check if it is
well mounted and rotates easily.
4
Put the lid (5) and close the clamps (6).
INFORMATION ON FRUIT AND VEGETABLES
Fruit/vegetables Centrifuging speed Fruit/vegetables Centrifuging speed
Pineapples II Carrots II
Blueberries I Melons I
Peaches I Apricots I
Beetroots I Nectarines I
Pears I Cucumbers I
Apples I Kiwi I
Cabbage II Tomatoes I
Fennel I Celery II
Raspberries I Grapes I
