67
5
Put the pusher (7) to the feeding tube.
6
Insert the pulp container (8) under the lid (5) in the
following way: lean the pulp container and place it under
a cover of the juice collector (3) and the lid (5), and next push
it towards the motor (1).
7
Place the juice collector under the lip (h).
Place washed fruit and vegetables prepared for juice
●
extraction near the appliance.
Start-up of the juice extractor
and operation (Fig. E)
1
Plug the juice extractor.
The appliance has an additional protection. If it is
plugged and the button power (a) is on and if the
switch is pulsating red, it means that either the body
(3) or the clamps (6) were improperly placed on the lid.
In such a situation the appliance cannot be started.
Check again whether the assembly is proper until the
lamp (c) turns blue.
2
Press the button power (a) – the juice extractor will
operate on gear 1 and the control lamp will turn blue. It is
a gear recommended for fruit.
3
If you need operations on gear 2 (high rotation for hard
fruit like carrots, celeries, beetroots, apples, etc.), press (for
a short time, max. 2 sec.) the button (b) – the lamp (c) will
shine red with a continuous light. If it is necessary to return
to gear 1, press for a short time the button (b) and the juice
extractor will return to gear 1, the control lamp will shine blue
with a continuous light.
The juice extractor always start working on gear 1.
An examplar table containing detailed information
about selecting a relevant gear for specic fruit and
vegetables may be found on page 66.
Put fruit or vegetables of relevant size into the feeding
●
tube (if necessary, they should be cut into pieces of
relevant size) and press them slightly with the pusher.
You must not push the products with your ngers or
other objects.
4
In case of the necessity (in case of excessive accumulation
of the pulp on the lter, which causes juice extractor vibrations)
you can use turbo button. To this end, press the button (b)
for a longer time (about 3 sec.). The engine operates in such
a case on maximal rotation for approximately 2 seconds. After
this time, the turbo function switches off automatically, and the
engine returns to previous rotation.
ATTENTION! Repeated usage of turbo function can
take place after min. 10 seconds.
Do not overload the appliance with extensive amount
of product or do not push it to strong (with a pusher),
because a sudden increase of juice amount in the bowl
spout can cause the juice overow out of the lid or into
pulp collector.
After operation (centrifuging of juice) (Fig. D)
1
Switch the juice extractor off, turning the button (a), the
lamp (c) will go out.
2
Unplug the appliance.
After the engine stops, start to disassemble the juice
●
extractor in order to wash the parts (see „Preparation of
the juice extractor for operation”).
Remove the accumulated pulp from the pulp container
●
(8).
Prevent the excess of the pulp container (8). The
excessive pulp can pour out while leaning the
container during removing.
Juice extractor maintenance rules
Clean the juice extractor carefully after each usage, to
●
prevent drying of juice and fruit remains.
Remove the dirt from the corners with a bottle brush or
●
tooth brush.
Clean the motor with a damped cloth sprinkled with
●
washing up liquid. Then dry it.
When water or juice gets into the motor, stop operation
and bring the appliance to the service centre for
inspection.
The following elements of the equipment: the juice
●
collector (2), the lid (5), the pusher (7) and the pulp
container (8) should be washed in hot water with
wash-up liquid.
You can also clean them in dishwashers in maximum
●
temperature 60°C.
The exception is the lter
●
(4). It should be washed with
a hard brush only. Do not use any metal brushes to
clean the lter!
As a result of a long use of the appliance, some plastic
●
elements can change their colour. Do not treat it as
a defect.
Colour from carrots can be removed by cleaning the
●
surface with a cloth moistened with edible oil.
Dry carefully all parts after cleaning.
●
Assemble the juice extractor according to the instructions
●
described above (see “Preparation of the juice
extractor for operation”).
Roll the supplying cord inside the compartment located
●
in the base of the juice extractor motor.
Pay special attention to transparent plastic parts.
They are sensitive to hits and falls. They may easily
be damaged then.
What to do when …
The appliance does not work:
Plug another appliance into the socket and check whether –
it works properly.
Return the appliance to authorized service facility. –
