ASRock 3U8G-C612/V [23/59] Hard drive
![ASRock 3U8G-C612/V [23/59] Hard drive](/views2/1694134/page23/bg17.png)
18 19
English
3.2 Hard Drive
3.2.1 Installing a Hard Disk Drive into 2.5" Hard Drive Tray
e 3U8G series chassis supports hot-swappable 2.5" hard drives. Six 2.5" hard drive
trays are located on the rear of the chassis.
Removing 2.5” Hard Drive Trays from the Chassis
1. Press the locking lever latch on the drive tray to unlock the retention lever.
2. Rotate the lever out and away from the module bay and pull the hard drive out of the
HDD tray.
2
1
