3U8G Series
26 27
English
FAN Flow Switch Jumper
(3-pin FAN_FLOW_SW1)
For Passive Card
Front-to-back air ow
(Default)
For Active Card
Back-to-front air ow
7. Place the GPGPU Card back into the Slot
8. Put the top front cover back. en power on the system.
