ASRock 3U8G-C612/V [43/59] English
![ASRock 3U8G-C612/V [43/59] English](/views2/1694134/page43/bg2b.png)
38 39
English
4. Install the add-on card, such as a graphics card, to the riser card.
4
5. Align the plate of the add-on card with the openings in the back of the chassis. Attach
the add-on card to the chassis with the screw that was previously set aside.
5
